Shimano SLX FH-M7110 Center Lock Disc 12 Mm Thru-Axle Rear Hub

The SLX FH-M7110 Rear Hub by Shimano – Quicker engagement
The Shimano SLX FH-M7110 rear hub is based on the innovative Micro Spline freehub system, which allows 12-speed cassettes with 10-tooth sprockets to be mounted. A fast engagement benefits acceleration and riding fun. Thanks to spline mount and a center lockring, the brake rotor can be easily mounted on this 12 x 142 mm hub.
Specifications:Series:SLX M7100Application:All Mountain, Enduro, Cross CountryBrake Type:Center Lock DiscFreehub Body Type:Aluminium, Direct Engagement (Ratchet), Quick Engagement (max. 7°)Technical Information:Body Material:aluminiumBearings:cup & coneSeals:labyrinth + contactFeatures:faster acceleration for more riding pleasuresmaller diameter for 10 T sprocket (Micro Spline)easy setup and reliable trail performancebrake rotor can be quickly mounted with spline mount and lockringflange diameter 69.8 mm left, 69.8 mm right6.72 mm offsetCBN precision machined bearings/polishedsteel axleanodised hub shellfreehub body has contact sealquick engagementTechnology:E-Thru
E-Thru is a tool-free thru-axle system from Shimano that optimises the stiffness-to-weight ratio and ensures easy handling via its reliable internal cam mechanism. It is characterised by a high torsion resistance and thus also supports cornering at high speed. E-Thru thru-axle hubs and thru-axles are available in the corresponding over locknut dimensions for front and rear.

Cup and Cone Bearings
Angular contact ball bearings of the cup & cone type are superior to sealed cartridge bearings in terms of load carrying capacity, as they distribute lateral and vertical forces better, and thus run particularly smoothly and last a long time. They are also easier to adjust, maintain and replace.

Micro Spline
Micro Spline is an innovative tooth profile on MTB freehub bodies from Shimano. All Shimano 12-speed MTB cassettes with a 10-speed sprocket are equipped with Micro Spline freehub toothing. The significantly higher and finer toothing enables a stiffer connection between the cassette and the hub body. The resulting increased contact area ensures reliable power transmission, minimises wear and prevents deformation of the freehub and sprocket.
Models:12 x 142 mm / 28 hole / Shimano Micro Spline:
Over Locknut Dimension:12 x 142 mm thru-axleSpoke Hole Count:28 holeFreehub:Shimano Micro SplineGearing:12-speedFlange Distance (L/R):55.17 mm (34.31 mm/20.86 mm)Partial Bolt Circle Diameter (L/R):61 mm/61 mmManufacturer Number:E-FHM7110C
12 x 142 mm / 32 hole / Shimano Micro Spline:
Over Locknut Dimension:12 x 142 mm thru-axleSpoke Hole Count:32 holeFreehub:Shimano Micro SplineGearing:12-speedFlange Distance (L/R):55.17 mm (34.31 mm/20.86 mm)Partial Bolt Circle Diameter (L/R):61 mm/61 mmManufacturer Number:E-FHM7110BContents:1 x Shimano SLX FH-M7110 rear hub
