Focus ATLAS 6.7 EQP 28″ Gravel Bike

The ATLAS 6.7 EQP Gravel Bike by FOCUS – For touring and commuting
The FOCUS ATLAS 6.7 EQP is a fully-equipped gravel bike with hub dynamo lights, pannier rack and fenders that can handle any adventure. It also features 2×10-speed derailleurs from Shimano GRX, a stable Novatec Boost rear hub and wheels from WTB. Based on an aluminium frame with carbon fork, the ATLAS 6.7 EQP offers generous tyre clearance. Thanks to disc brakes and flared handlebars, this bike steers safely and comfortably across all surfaces and even under adverse weather conditions.
Specifications:Application:Gravel, City & TouringWheel Size:28″Sizes:XS, S, M, L, XLFrame Material:aluminiumFork Material:CarbonComponents:Frame:FOCUS ATLAS, Flat Mount Disc, 12 x 148 mm thru-axleFork:FOCUS ATLAS Carbon, Flat Mount Disc, 12 x 110 mm thru-axle, 425 mm axle to crown length, 50 mm offsetStem:aluminium, 31.8 mm, 6°Handlebars:Aluminium, 31.8 mm, 116 mm drop, 74 mm reach, 10° flareHeadset:Acros IS52/28.6-IS52/40, FOCUS integrated C.I.S.Seatpost:Aluminium, 27.2 mm, 350 mm, 0 mm setbackSaddle:WTB SL8Crank:Shimano GRX 600, 30-46 t, BSA bottom bracketPedals:noneBrakes:Shimano GRX 400, 160 mm/160 mmShift/Brake lever:Shimano GRX 400Rear Derailleur:Shimano GRX 400Front Derailleur:Shimano GRX 400Cassette:Shimano CS-HG50-10, 10-speed, 11-36 tChain:Shimano Tiagra CN-4601Wheels:WTB ST i23 TCS rims, Tubeless Ready, Shutter Precision PL-7 hub dynamo, 12 x 110 mm, Novatec D041 rear hub, 12 x 148 mm, Shimano freehubTyres:WTB Riddler, 700 x 37CApproved For:Weight Limit:120 kgRotor Size (max.):180 mmTyre Size (max.):27.5″ x 2.0″ , 47-622 (700 x 47C), with fenders: 40-622 (700 x 40C)Features:light, robust aluminium bike with carbon fork (475 g)fully equipped EQP model, prepared for extended trips and commuting51 mm plastic Buechel mudguardstwo-leg aluminium luggage rack, 20 kg maximum loadkickstand parking support, 18 mm adapterHerrmans H-Black MR8 LED front lightHerrmans H-Trace Mini LED rear lightwide flared handlebars and disc brakes offer a high degree of safety and comfortpleasant shifting thanks to Shimano gravel derailleurRoad Boost for high stability through better spoke tensionhigh tyre clearance with simultaneously short chainstaysstreamlined cockpit with cable routing from the handlebars directly into the headset; space for handlebar bagcan be ridden with 650B wheelsmounts for 3 bottle cages (seat tube, top of down tube, bottom of down tube)various mounting options for equipment (3 kg payload at the fork)FOCUS SL handlebar tapedouble-sealed bearingsASTM Category 2Technology:C.I.S.
The fully integrated C.I.S. cable routing ensures a tidy cockpit. All cables run through the special stem and headset directly into the frame. Perfect braking and shifting is guaranteed at all times.

S.S.P.S.
The Stable Stiffness per Size (S.S.P.S.) process means that each frame size receives a specially-tuned carbon lay-up and is individually constructed. This is the only way to ensure an optimal stiffness-to-weight ratio and equal riding characteristics for each size.

Road Boost
The FOCUS hub standard Road Boost ensures optimum shifting characteristics thanks to a perfect chainline and a minimum level of wear and noise. At the same time, the wider hubs increase the rigidity of the wheels, resulting in reliable handling characteristics and high durability.
Geometry:XS:
Recommended Height:160 – 170 cmFrame Size:48 cmStack:568 mmReach:370 mmSeat Tube Length:450 mmEffective Top Tube Length:532 mmHead Tube Length:114 mmChainstay Length:425 mmWheelbase:1015 mmBB Drop:75 mmSeat Tube Angle:74°Head Tube Angle:70.5°Standover Height:765 mmStem Length:70 mmHandlebar Width:42 cmCrank Arm Length:170.0 mmWheel Size:28″
S:
Recommended Height:171 – 175 cmFrame Size:51 cmStack:582 mmReach:380 mmSeat Tube Length:490 mmEffective Top Tube Length:552 mmHead Tube Length:129 mmChainstay Length:425 mmWheelbase:1030 mmBB Drop:75 mmSeat Tube Angle:73.5°Head Tube Angle:70.5°Standover Height:789 mmStem Length:70 mmHandlebar Width:42 cmCrank Arm Length:170.0 mmWheel Size:28″
M:
Recommended Height:176 – 185 cmFrame Size:54 cmStack:596 mmReach:395 mmSeat Tube Length:520 mmEffective Top Tube Length:571 mmHead Tube Length:144 mmChainstay Length:425 mmWheelbase:1051 mmBB Drop:75 mmSeat Tube Angle:73.5°Head Tube Angle:70.5°Standover Height:809 mmStem Length:80 mmHandlebar Width:44 cmCrank Arm Length:172.5 mmWheel Size:28″
L:
Recommended Height:186 – 190 cmFrame Size:57 cmStack:615 mmReach:410 mmSeat Tube Length:550 mmEffective Top Tube Length:592 mmHead Tube Length:164 mmChainstay Length:425 mmWheelbase:1072 mmBB Drop:75 mmSeat Tube Angle:73.5°Head Tube Angle:70.5°Standover Height:830 mmStem Length:90 mmHandlebar Width:44 cmCrank Arm Length:172.5 mmWheel Size:28″
XL:
Recommended Height:191 – 199 cmFrame Size:60 cmStack:643 mmReach:420 mmSeat Tube Length:577 mmEffective Top Tube Length:610 mmHead Tube Length:194 mmChainstay Length:425 mmWheelbase:1092 mmBB Drop:75 mmSeat Tube Angle:73.5°Head Tube Angle:70.5°Sta
