Dt-swiss 350 Classic MTB 6-Bolt Disc Rear Hub

The 350 Classic 6-bolt Disc rear hub by DT Swiss for MTB wheels
This 350 MTB rear hub from DT Swiss is designed for classic J-Bend spokes and a 6-bolt brake rotor. Its core is a resilient freehub with Ratchet 36 System and precision star ratchets. Thanks to the no-tool concept, the hub can be easily maintained without the use of tools. The end caps are shaped in such a way that uncomplicated and, above all, quick disassembly is possible. This is an advantage especially during races, but easy wheel removal is also an asset if you have a second wheelset that you use depending on the course or conditions. The sturdy aluminium hub body ensures a long service life, as do the steel bearings. The bearing play has been minimised and optimised. This is made possible by preloading the bearings before the hub is not clamped in the frame. Once fastened with the thru-axle, the preload is released and the bearings are maximally slidable. Thanks to the precision seals, they are also excellently protected against moisture and dirt.
Specifications:Application:All Mountain, Enduro, DownhillBrake Type:6-bolt discFreehub Body Type:Ratchet System 36Technical Information:Body Material:aluminiumBearings:steel bearingsSeals:precision sealFeatures:no-tool concept for tool-free maintenancequick disassembly possible thanks to the special shape of the end capsoptimised bearing clearance due to preloading before the hub is installedaluminium freehub body100% Swiss-madeTechnology:Ratchet System®
The patented freehub system with high-precision star ratchets guarantees maximum load capacity and reliability. Thanks to the no-tool concept, the system is very easy and quick to maintain.
Models:12 x 142 mm / 28 hole / Shimano:
Over Locknut Dimension:12 x 142 mm thru-axleSpoke Hole Count:28 holeFreehub:Shimano MTBGearing:8-/9-/10-/11-speedFlange Distance (L/R):33.6 mm / 20.4 mmPartial Bolt Circle Diameter (L/R):60.0 mm / 50.5 mmManufacturer Number:H350NDDBR28SA0478S
12 x 142 mm / 32 hole / Shimano:
Over Locknut Dimension:12 x 142 mm thru-axleSpoke Hole Count:32 holeFreehub:Shimano MTBGearing:8-/9-/10-/11-speedFlange Distance (L/R):33.6 mm / 20.4 mmPartial Bolt Circle Diameter (L/R):60.0 mm / 50.5 mmManufacturer Number:H350NDDBR32SA0478S
12 x 150 mm / 32 hole / Shimano:
Over Locknut Dimension:12 x 150 mm thru-axleSpoke Hole Count:32 holeFreehub:Shimano MTBGearing:8-/9-/10-/11-speedFlange Distance (L/R):41.1 mm / 27.9 mmPartial Bolt Circle Diameter (L/R):60.0 mm / 53.1 mmManufacturer Number:H350LDDBR32SA2444S
12 x 142 mm / 28 hole / SRAM XD:
Over Locknut Dimension:12 x 142 mm thru-axleSpoke Hole Count:28 holeFreehub:SRAM XDFlange Distance (L/R):33.6 mm / 20.4 mmPartial Bolt Circle Diameter (L/R):60.0 mm / 50.5 mmManufacturer Number:H350NDDRR28SA0000S
12 x 142 mm / 32 hole / SRAM XD:
Over Locknut Dimension:12 x 142 mm thru-axleSpoke Hole Count:32 holeFreehub:SRAM XDGearing:11-/12-speedFlange Distance (L/R):33.4 mm / 30.4 mmPartial Bolt Circle Diameter (L/R):60.0 mm / 50.5 mmManufacturer Number:H350NDDRR32SA0000S
12 x 150 mm / 32 hole / SRAM XD:
Over Locknut Dimension:12 x 150 mm thru-axleSpoke Hole Count:32 holeFreehub:SRAM XDGearing:11-/12-speedFlange Distance (L/R):41.1 mm / 27.9 mmPartial Bolt Circle Diameter (L/R):60.0 mm / 53.1 mmManufacturer Number:H350LDDRR32SA2430SContents:1 x DT Swiss 350 Classic MTB 6-bolt Disc rear hub
