Dt-swiss 240 Straight Pull Road Rear Hub

DT Swiss 240 Straight Pull Road rear hub – the classic for rim brakes, but reissued
The 240 Straight Pull Road rear hub from DT Swiss is a stable but light hub for road bikes with rim brakes. The Ratchet EXP freehub is equipped with the latest technology and has 36 teeth. In this way a large contact surface is created, which ensures high power transmission. The bearings are integrated into the threaded rings, thus increasing the distance between the bearings. As a result, the hub is stiffer, which leads to less load on the bearings, increasing their durability. The no-tool concept is particularly practical. This allows you to service the hub without any tools. Even if you want to change the freehub body, no tools are required.
Specifications:Application:RoadBrake Type:rim brakeFreehub Body Type:Ratchet EXP 36Technical Information:Body Material:aluminiumBearings:steel bearingsSeals:precision sealTechnology:Ratchet EXP:
A ratchet and a threaded ring are integrated into the hub. This reduces the number of components required, resulting in less wear and tear and a lower weight. In addition, the heavy-duty and reliable ratchet system can be easily and quickly maintained. The no-tool concept plays a decisive role, as it allows the freehub to be replaced without any tools. The freehub has two ratchets which engage simultaneously. This means that the contact surface is large and the point load is kept small, which relieves the material and allows the freehub to work particularly reliably and precisely.
Models:10 x 130 mm / 24 hole / Shimano:
Over Locknut Dimension:10 x 130 mm quick releaseSpoke Hole Count:24Freehub:Shimano RoadGearing:8-/9-/10-/11-/12-speedNote:The assembly of 8-/9-/10-speed cassettes on a Shimano Road freehub body requires a 1.85 mm spacer ring.Flange Distance (L/R):49.1 mm (33.4 mm/15.7 mm)Partial Bolt Circle Diameter (L/R):37.2 mm/44.1 mmManufacturer Number:H24PHRQIR24SA4814S
10 x 130 mm / 24 hole / SRAM XDR:
Over Locknut Dimension:10 x 130 mm quick releaseSpoke Hole Count:24Freehub:SRAM XDRGearing:11-/12-speedNote:A 1.8 mm spacer is required to mount XD cassettes on an XDR freehub body.Flange Distance (L/R):49.1 mm (33.4 mm/15.7 mm)Partial Bolt Circle Diameter (L/R):37.2 mm/44.1 mmManufacturer Number:H24PHRQ1R24SA4974SContents:1 x DT Swiss 240 Straight Pull Road rear hub
