Commencal Meta TR ÖHLINS Edition 29″ Mountain Bike

The COMMENCAL Meta TR 29″ Mountain Bike in the ÖHLINS Edition
The COMMENCAL Meta TR ÖHLINS AXS 29″ mountain bike with ÖHLINS suspension and a Shimano XT drivetrain is the right bike for sporty trail and enduro ambitions. The ÖHLINS TTX1 Air shock and the RXF36 suspension fork with 150 mm travel score with a wide range of adjustment options and sensitive, precise damping response. The playful linkage design makes the Meta TR dynamic, while double-row bearings on the frame prevent the loss of rigidity at the joints. The result is a bike that delivers high performance on any terrain and won’t let you down on difficult sections.
Specifications:Application:All Mountain, EnduroWheel Size:29″Front Travel:150 mmRear Travel:140 mmSizes:S, M, L, XLFront Triangle Material:aluminium (6066)Rear Triangle Material:aluminium (6066)Components:Frame:COMMENCAL 2022 Meta TR 29, triple butted, 12 x 148 mm (Boost)Fork:ÖHLINS RXF36 m.2, TTX 18 damper cartridge, Ramp-up air chamber, low-speed compression, high-speed compression, rebound, 44 mm offset, 15 x 110 mm (Boost)Stem:Ride Alpha Freeride 40, 40 mm, 31,8 mmHandlebars:Ride Alpha R20, 20 mm Rise (S), R27, 27 mm Rise (M-XL), 31.8 mm, aluminium (6061)Grips:ODI Elite MotionRear Shock:ÖHLINS TTX1 Air, 210 x 55 mm, Climb Mode, adjustable High- and low speed compression, adjustable reboundRemote System:noneHeadset:Acros ZS 44 – ZS 56, sealed bearingsSeatpost:KindShock LEV Integra, 34.9 mm, travel: 125 mm (S), 150 mm (M), 175 mm (L), 200 mm (XL), with SouthPaw RemoteSaddle:SDG Bel Air V3 Atmos, Lux-Alloy railsCrank:Shimano XT, 170 mm, 32 teeth, Dynamic Chain Engagement+, Boost, with Shimano BBMT800 press fit bottom bracketPedals:noneBrakes:Shimano XT 4-piston, I-Spec EV compatibleShift Lever:Shimano XT, 12-speedRear Derailleur:Shimano XT, 12-speedCassette:Shimano XT, 12-speed, 10 – 51 teethChain:Shimano XT, 12-speedRims:DT Swiss XM1700 SPLINE, 28-bolt, 30 mm jaw widthSpokes:DT Swiss Competition, straight pull, 2.0 – 1.8 – 2.0 mm, double butted, stainless steel, with Nylok, blackFront Hub:DT Swiss 350, 28 holes, sealed bearings, 15 x 110 mm (Boost)Rear Hub:DT Swiss 350, Shimano Micro Spline, 36-tooth pawl freehub, 28 holes, sealed bearings, 12 x 148 mm (Boost)Front Tyre:Schwalbe Magic Mary, 29 x 2.4″ , Super Trail, Addix Soft, Tubeless EasyRear Tyre:Schwalbe Nobby Nic, 29 x 2.35″ , Super Trail, Addix Soft, Tubeless EasyApproved For:Rotor Size (max.):220 mm (rear)Tyre Size (max.):29 x 2.5″ (rear)Chainrings:1xFork Axle to Crown Size (max.):571 mmFeatures:with flip chip on the damper mount to adjust the geometrydynamic linkage designdesigned for rather short fork offsettriple butted frame tubes1 bottle cagerather steep seat tube angle for a good uphill riding positionenduro bearings for high rigidity and performanceGeometry:(based on a fork axle to crown length of 561 mm)
S:
Recommended Height:158 – 170 cmStack:626 mm (low), 623 mm (high)Reach:440 mm (low), 444 mm (high)Seat Tube Length:380 mmEffective Top Tube Length:566 mm (low), 565 mm (high)Head Tube Length:110 mmChainstay Length:435 mm (low), 434 mm (high)Wheelbase:1203 mm (low), 1202 mm (high)BB Drop:33 mm (low), 29 mm (high)Seat Tube Angle:78.6° (low), 79° (high)Head Tube Angle:64.5° (low), 65° (high)Handlebar Width:760 mm
M:
Recommended Height:168 – 180 cmStack:630 mm (low), 627 mm (high)Reach:465 mm (low), 469 mm (high)Seat Tube Length:420 mmEffective Top Tube Length:592 mm (low), 591 mm (high)Head Tube Length:115 mmChainstay Length:435 mm (low), 434 mm (high)Wheelbase:1230 mm (low), 1229 mm (high)BB Drop:33 mm (low), 29 mm (high)Seat Tube Angle:78.6° (low), 79° (high)Head Tube Angle:64.5° (low), 65° (high)Handlebar Width:780 mm
L:
Recommended Height:178 – 190 cmStack:634 mm (low), 631 mm (high)Reach:490 mm (low), 494 mm (high)Seat Tube Length:440 mmEffective Top Tube Length:618 mm (low), 617 mm (high)Head Tube Length:120 mmChainstay Length:435 mm (low), 434 mm (high)Wheelbase:1257 mm (low), 1256 mm (high)BB Drop:33 mm (low), 29 mm (high)Seat Tube Angle:78.6° (low), 79° (high)Head Tube Angle:64.5° (low), 65° (high)Handlebar Width:780 mm
XL:
Recommended Height:188 – 210 cmStack:638 mm (low), 635 mm (high)Reach:515 mm (low), 519 mm (high)Seat Tube Length:460 mmEffective Top Tube Length:644 mm (low), 643 mm (high)Head Tube Length:125 mmChainstay Length:435 mm (low), 434 mm (high)Wheelbase:1284 mm (low), 1283 mm (high)BB Drop:33 mm (low), 29 mm (high)Seat Tube Angle:78.6° (low), 79° (high)Head Tube Angle:64.5° (low), 65° (high)Handlebar Width:800 mmManufacturer Number:22METATROH
Shipping Notice:The shipment is sent pre-assembled by a forwarding agent.
The delivery time is extended by 2-5 days, depending on the overall volume of orders.
For individual consultation, please contact our customer service team.
Contents:1 x COMMENCAL Meta TR ÖHLINS Edition 29″ mountain bikeOrder Together:MTB Pedals
