Commencal Meta TR Essential 29″ Mountain Bike – 2022 Model

The COMMENCAL Meta TR Essential 29″ mountain bike offers fun and dynamic performance on trails with a Shimano SLX 12-speed drivetrain and brakes as well as Fox suspension elements. With the help of the Flip Chip on the shock mount, you can adjust the geometry to the road ahead, your preferences and your riding style in no time at all. and the dropper seatpost makes it easier to switch between uphill and downhill. The playful linkage design makes the Meta TR dynamic, while double-row bearings on the frame prevent the loss of rigidity at the joints. All of this results in a bike that can deliver high performance on any terrain, and won’t let you down on difficult passages.
Specifications:Application:All Mountain, EnduroWheel Size:29″Front Travel:150 mmRear Travel:140 mmSizes:S, M, L, XLFront Triangle Material:aluminium (6066)Rear Triangle Material:aluminium (6066)Components:Frame:COMMENCAL 2022 Meta TR 29, triple butted, 12 x 148 mm (Boost)Fork:Fox Racing Shox Performance, FIT Grip, 3-Position Adjust, Rebound, 44 mm Offset, 15 x 110 mm (Boost)Stem:Ride Alpha Freeride 50, 50 mm, 31,8 mmHandlebars:Ride Alpha R27, 31,8 mm, 780 mm length, 27 mm rise, aluminium (7050)Grips:ODI Elite MotionRear Shock:Fox Racing Shox Float DPS Performance, 3-Position Adjust, Rebound, 210 x 55 mmRemote System:noneHeadset:Acros ZS 44 – ZS 56, sealed bearingsSeatpost:Kind Shock Rage-I, 34,9 mm, Hub: 125 mm (S), 150 mm (M), 170 mm (L), 190 mm (XL), with SouthPaw RemoteSaddle:WTB Silverado narrow, steel rails (CrMo)Crank:Shimano SLX, 170 mm, 32-tooth, Dynamic Chain Engagement+, with Shimano BB71-41A bottom bracketPedals:noneBrakes:Shimano SLX 2-piston, compatible with I-Spec EV, with Shimano RT-MT800 brake rotors, Center-Lock, 203 mm (front) / 203 mm (rear)Shift Lever:Shimano SLX, 12-speedRear Derailleur:Shimano SLX, 12-speedCassette:Shimano SLX, 10-51-tooth, 12-speedChain:Shimano SLX, 12-speedRims:DT Swiss M502 SPLINE, 32-bolt, 30 mm jaw widthSpokes:DT Swiss Competition, J-Bend, 2.0 – 1.8 – 2.0 mm, double butted, stainless steel, with NylokFront Hub:Formula CL-811, 32-bolt, sealed bearingsRear Hub:Formula MSC-148A, 32-bolt, sealed bearingsFront Tyre:Maxxis Dissector, 29 x 2,4″ , WT, EXO, Tubeless ReadyRear Tyre:Maxxis Dissector, 29 x 2,4″ , WT, EXO, Tubeless ReadyApproved For:Rotor Size (max.):220 mm (rear)Tyre Size (max.):65 mm (rear)Chainrings:1xFork Axle to Crown Size (max.):571 mmFeatures:with flip chip on the damper mount to adjust the geometrydynamic linkage designdesigned for rather short fork offsettriple butted frame tubes1 bottle cagerather steep seat tube angle for a good uphill riding positionenduro bearings for high rigidity and performanceGeometry:(based on a fork axle to crown length of 561 mm)
S:
Recommended Height:160 – 171 cmStack:626 mm (low), 623 mm (high)Reach:440 mm (low), 444 mm (high)Seat Tube Length:380 mmEffective Top Tube Length:566 mm (low), 565 mm (high)Head Tube Length:110 mmChainstay Length:435 mm (low), 434 mm (high)Wheelbase:1203 mm (low), 1202 mm (high)BB Drop:33 mm (low), 29 mm (high)Seat Tube Angle:78.6° (low), 79° (high)Head Tube Angle:64.5° (low), 65° (high)
M:
Recommended Height:170 – 181 cmStack:630 mm (low), 627 mm (high)Reach:465 mm (low), 469 mm (high)Seat Tube Length:420 mmEffective Top Tube Length:592 mm (low), 591 mm (high)Head Tube Length:115 mmChainstay Length:435 mm (low), 434 mm (high)Wheelbase:1230 mm (low), 1229 mm (high)BB Drop:33 mm (low), 29 mm (high)Seat Tube Angle:78.6° (low), 79° (high)Head Tube Angle:64.5° (low), 65° (high)
L:
Recommended Height:180 – 191 cmStack:634 mm (low), 631 mm (high)Reach:490 mm (low), 494 mm (high)Seat Tube Length:440 mmEffective Top Tube Length:618 mm (low), 617 mm (high)Head Tube Length:120 mmChainstay Length:435 mm (low), 434 mm (high)Wheelbase:1257 mm (low), 1256 mm (high)BB Drop:33 mm (low), 29 mm (high)Seat Tube Angle:78.6° (low), 79° (high)Head Tube Angle:64.5° (low), 65° (high)
XL:
Recommended Height:190 – 203 cmStack:638 mm (low), 635 mm (high)Reach:515 mm (low), 519 mm (high)Seat Tube Length:460 mmEffective Top Tube Length:644 mm (low), 643 mm (high)Head Tube Length:125 mmChainstay Length:435 mm (low), 434 mm (high)Wheelbase:1284 mm (low), 1283 mm (high)BB Drop:33 mm (low), 29 mm (high)Seat Tube Angle:78.6° (low), 79° (high)Head Tube Angle:64.5° (low), 65° (high)Manufacturer Number:22METATRE
Shipping Notice:The shipment is sent pre-assembled by a forwarding agent.
The delivery time is extended by 2-5 days, depending on the overall volume of orders.
For individual consultation, please contact our customer service team.
Contents:1 x COMMENCAL Meta TR Essential 29″ Mountain BikeOrder Together:MTB Pedals
