Commencal Meta SX Ride 29″ / 27.5″ Mountain Bike

The Meta SX Ride 29″ /27.5″ Mountain Bike by COMMENCAL with RockShox and SRAM components
The COMMENCAL Meta SX mountain bike with 29″ front wheel and 27.5″ rear wheel for enduro trails is equipped with RockShox suspension as well as a SRAM SX drivetrain and Guide T brakes. A flip chip allows you to quickly and easily adjust the geometry in two settings.
Specifications:Application:EnduroWheel Size:Scaled SizingFront Travel:170 mmRear Travel:160 mmSizes:S, M, L, XLFront Triangle Material:aluminium (6066)Rear Triangle Material:aluminium (6066)Components:Frame:COMMENCAL 2022 Meta SX 29, double butted, 12 x 148 mm (Boost)Fork:RockShox ZEB, Charger damper, DebonAir, Rebound, 1 token, 44 mm offset, 15 x 110 mm (Boost)Stem:Ride Alpha Freeride 40, 40 mm, 31,8 mmHandlebars:Ride Alpha R20, 20 mm Rise (S), R27, 27 mm Rise (M-XL), 31.8 mm, aluminium (6061)Grips:ODI Elite MotionRear Shock:RockShox Deluxe Select+, 2 Token, Rebound, Threshold Adjustment, 230 x 65 mmRemote System:noneHeadset:Acros ZS44 – ZS56, sealed bearingsSeatpost:Kind Shock Rage-I, 34,9 mm, Hub: 125 mm (S), 150 mm (M), 170 mm (L), 190 mm (XL), with SouthPaw RemoteSaddle:SDG Bel Air V3, steel railsCrank:SRAM X1 1000 Eagle, 170 mm, 32 teeth, DUB, Boost, with SRAM DUB Pressfit bottom bracketPedals:noneBrakes:SRAM Guide T 4-piston, compatible with Matchmaker, with SRAM G2 CleanSweep brake rotors, 6-bolt, 200 mm/200 mmShift Lever:SRAM SX Eagle, 12-speedRear Derailleur:SRAM SX Eagle, 12-speedCassette:SRAM PG-1210, 11-51 tooth, 12-speedChain:SRAM NX Eagle, 12-speedRims:e*thirteen LG1 EN Base, 32 holes, 30 mm jaw width, 29″ (front), 27.5″ (rear)Spokes:Sapim Leader, J-Bend, 2.0 mm, stainless steel, with NylokFront Hub:Formula DC-711, 32-bolt, sealed bearingsRear Hub:Formula DCL-348A, 32-bolt, sealed bearingsFront Tyre:Maxxis Assegai, 29 x 2.5″ , WT, 3C MaxxTerra, EXO, Tubeless ReadyRear Tyre:Maxxis DHR II, 27.5 x 2.4″ , WT, 3C MaxxTerra, EXO+, Tubeless ReadyApproved For:Rotor Size (max.):220 mm (rear)Tyre Size (max.):27.5 x 2.7″ (rear)Chainrings:1xFork Axle to Crown Size (max.):596 mmFeatures:with flip chip on the damper mount to adjust the geometry29″ front wheel for smooth running and fun climbs27.5″ rear wheel for responsive handlingcentral riding position1 bottle cagedouble row Enduro Bearings for high stiffness and reliabilitywith ISCG-05 mount for a chain guideGeometry:(based on a fork axle to crown length of 586 mm)
S:
Recommended Height:158 – 170 cmStack:633 mm (low), 630 mm (high)Reach:436 mm (low), 440 mm (high)Seat Tube Length:380 mmEffective Top Tube Length:570 mm (low), 569 mm (high)Head Tube Length:115 mmChainstay Length:443 mm (low), 442 mm (high)Wheelbase:1232 mm (low), 1231 mm (high)BB Drop:-1.5 mm (low), +4 mm (high)Seat Tube Angle:78.1° (low), 78.5° (high)Head Tube Angle:63.6° (low), 64° (high)Handlebar Width:760 mm
M:
Recommended Height:168 – 180 cmStack:637 mm (low), 634 mm (high)Reach:456 mm (low), 460 mm (high)Seat Tube Length:420 mmEffective Top Tube Length:591 mm (low), 590 mm (high)Head Tube Length:120 mmChainstay Length:443 mm (low), 442 mm (high)Wheelbase:1254 mm (low), 1253 mm (high)BB Drop:-1.5 mm (low), +4 mm (high)Seat Tube Angle:78.1° (low), 78.5° (high)Head Tube Angle:63.6° (low), 64° (high)Handlebar Width:780 mm
L:
Recommended Height:178 – 190 cmStack:642 mm (low), 639 mm (high)Reach:481 mm (low), 485 mm (high)Seat Tube Length:440 mmEffective Top Tube Length:617 mm (low), 616 mm (high)Head Tube Length:125 mmChainstay Length:443 mm (low), 442 mm (high)Wheelbase:1286 mm (low), 1285 mm (high)BB Drop:-1.5 mm (low), +4 mm (high)Seat Tube Angle:78.1° (low), 78.5° (high)Head Tube Angle:63.6° (low), 64° (high)Handlebar Width:780 mm
XL:
Recommended Height:188 – 210 cmStack:647 mm (low), 643 mm (high)Reach:506 mm (low), 510 mm (high)Seat Tube Length:460 mmEffective Top Tube Length:644 mm (low), 643 mm (high)Head Tube Length:130 mmChainstay Length:443 mm (low), 442 mm (high)Wheelbase:1313 mm (low), 1312 mm (high)BB Drop:-1.5 mm (low), +4 mm (high)Seat Tube Angle:78.1° (low), 78.5° (high)Head Tube Angle:63.6° (low), 64° (high)Handlebar Width:800 mmManufacturer Number:22METAAMRI
Shipping Notice:The shipment is sent pre-assembled by a forwarding agent.
The delivery time is extended by 2-5 days, depending on the overall volume of orders.
For individual consultation, please contact our customer service team.
Contents:1 x COMMENCAL Meta SX Ride 29″ / 27.5″ mountain bikeOrder Together:MTB Pedals
